R4N-2014-23-1024-WT 4P 24VDC IP40 INDUSTRIAL 4 POLE
Electromagnetic relay, industrial - miniature, for a socket. Width 21.2 mm. Output: 4 CO - four changeover contacts - pins: 11 (9), 12 (1), 14 (5); 21 (10), 22 (2), 24 (6); 31 (11), 32 (3), 34 (7); 41 (12), 42 (4), 44 (8); W mechanical indicator, red L LED indicator, T test button with locking function. Dimensions: 27.5 x 21.2 x 35.6 mm. IP 40. Contact material: AgNi. Matching Sockets: GZT4, GZM4, GZ4, GS4, GZP4, SU4D, SU4L, G4
DEPTH | 27.4 mm |
NUMBER OF SWITCHING CONTACTS | 4 |
RATED CURRENT | 7 A. |
WIDTH | 21 mm |
HEIGHT | 35.5 mm |
RATED CONTROL VOLTAGE US FOR DC | 24 V |
COMPLETE WITH SOCKET | Not |
CONTROL VOLTAGE TYPE | DC |
TYPE OF ELECTRICAL CONNECTION | Plug connection |
PROTECTION CLASS (IP) | IP40 |
DRIVE POLARITY | Not polarized |
CONTACT MATERIAL | Nickel |
CONTACT TYPE | Single |
WITH FORCED CONTACT LEADING | Not |
DRIVE SWITCHING MODE | Monostable |
CONTACT COVER MATERIAL | Silver |
