CIRCUIT BREAKER 3P C 25A 6kA DIN EVOZ3C25 TRACON C6
PARAMETERS:
| Trigger characteristics: | C |
| Number of poles (total): | 3 |
| Number of poles: | 3 |
| Nominal current: | 25A |
| Nominal voltage: | 400V |
| Rated insulation voltage Ui: | 500V |
| Rated impulse withstand voltage Uimp: | 4kV |
| Rated short-circuit making capacity Icn according to EN 60898 at 230 V: | 6kA |
| Voltage type: | AC |
| Rated short-circuit making capacity Icn according to EN 60898 at 400 V: | 6kA |
| Frequency range: | 50 - 60 Hz |
| At the same time, the N pole is disconnected: | NO |
| Possibility of additional equipment: | Yes |
| Width expressed in number of modules: | 3 |
| Degree of protection (IP): | IP20 |
| Ambient temperature in operating conditions: | - 25 - 55 °C |
| Cross-section of the connected single-wire wire: | 1 - 25mm² |
